HAUS LOGIC
KNX backbone systems engineered for the scale and operating standard of Emirates Hills mansions. Lighting, climate, shading, security, networking and energy on one open architecture.
Typical villa size
12,000–25,000 sq ft
Mansion-scale villas with three to five floors and dedicated staff quarters.
Community
Gated, 24/7 security
Community guard plus per-villa security; system must coordinate with both.
Climate consideration
55°C summer peaks, high dust load
Cooling load is the dominant energy concern; HVAC and shading must be tightly coupled.
Landscape constraint
Mature landscaping with irrigation
Smart irrigation tied to weather data is standard, not optional.
KNX backbone, Home Assistant overlay, vendor-agnostic integration. Engineered for 55°C summer peaks and the operating conditions of the UAE grid.
Capability
Every fixture in the Emirates Hills villa is addressable through KNX, so scenes are not a remote-control trick, they are deterministic states the system holds reliably across decades. Circadian sequences run for the family, evening scenes drop ambient layers for entertaining, and security scenes hold the property at night. DALI is layered in for tunable-white and dimming on architectural luminaires.
Capability
In the 55°C Dubai summer, climate is the highest-load subsystem. KNX integrates the VRF or chilled-water plant alongside underfloor heating, fresh-air units, and humidity control. Per-room setpoints, presence-aware setbacks, and external-temperature compensation reduce energy waste without compromising comfort, even in 55C peaks.
Capability
Motorised blinds and pergola shading respond to azimuth and indoor temperature, not just timers. The system pre-cools rooms by closing west-facing shades before peak sun, opens eastern facades for morning light, and protects interiors from UV degradation. Override is always one tap away from any wall switch or dashboard.
Capability
Access control, intrusion, video surveillance, and gate intercom integrate at the bus level rather than depending on a vendor app. Camera events trigger lighting, scene changes, and notifications. Smart locks log entries against named users. The system runs locally and continues to function during internet outages.
Capability
Enterprise Wi-Fi (Ubiquiti or equivalent), VLAN-segregated IoT, hardwired backbone, and offsite VPN form the substrate. Coverage is engineered against survey, not guessed. Guest, family, staff, and IoT traffic are isolated. CCTV and automation never share the same broadcast domain as personal devices.
Capability
Whole-villa metering, circuit-level submetering, solar PV integration where present, and EV charger orchestration are coordinated through KNX and Home Assistant. Loads are shed or shifted in response to peak tariff, generation, and battery state. Owners get monthly reports against benchmarks for similar villas.
Capability
Home Assistant runs locally on the property. It overlays the KNX backbone with rich, custom dashboards on iPad wall panels, in-app on iOS and Android, and on hidden touch panels in primary spaces. Dashboards are tuned per user, owner, family, staff, security, with role-appropriate controls only.
Emirates Hills villas are mansion-scale residences where every subsystem operates at a level several times larger than a standard family home. A typical project here covers three to five storeys, multiple staff zones, deep landscaping, a pool deck, a majlis wing, and often a separate guest house. The automation system has to coordinate all of that without becoming the single thing the family complains about every weekend.
The community itself enforces a security and aesthetic standard that rules out improvised solutions. Switch finishes have to match interior schemes from the world's top designers; controllers have to be hidden, not on display. Network coverage has to span large footprints with thick walls, full pool decks, and external garden lighting zones. Climate load is dominated by Dubai's 55°C summers, which means HVAC, fresh air, and shading must be controlled together as one system, not as three separate apps.
Our approach for Emirates Hills is invariant: KNX as the wired backbone for everything that controls the building (lighting, blinds, climate, scenes), Home Assistant as the local intelligence and dashboard layer, and brand-neutral hardware selection so the family is never locked into one supplier for the next 30 years. The system is documented, commissioned, and serviceable by any KNX-certified integrator after we hand over.
Complete KNX automation for a private villa in Dubai, featuring Zennio Z50 room controllers, Gira HomeServer visualisation, and intelligent presence-based control throughout. The system integrates lighting, climate, and blinds with automated scenes that adapt to occupancy.
عرض المشروع
Comprehensive KNX automation for a large family villa in Abu Dhabi featuring EIBport v3 for centralised visualisation and control. Jung keypads throughout provide elegant, tactile control of lighting and scenes, while UniFi networking ensures seamless connectivity for the entire property including outdoor entertainment areas.
عرض المشروعBook a private site assessment with our principal engineer. We document the villa, discuss priorities, and deliver a fixed-scope proposal.
Book your site assessment
