Private Yacht, Mangusta 104 REV

KNX and DALI lighting control commissioning on a 32 m yacht in Abu Dhabi

Haus Logic delivers wired marine automation, KNX and DALI, for yachts as well as villas, apartments and offices. On this privately owned Mangusta 104 REV, a 31.8 metre motor yacht berthed in Abu Dhabi, Haus Logic was engaged to resolve control issues on an existing KNX and DALI lighting installation by others, operated by the crew from the SeaLux app on an iPad. The work covered system diagnostics, DALI compatibility resolution, re-programming and commissioning, returning the lighting to reliable control from the app. Haus Logic also provides annual maintenance contracts (AMC) that protect onboard lighting and control systems and minimise operational risk. Photographs show the Mangusta 104 REV model and are by Mangusta Yachts (Overmarine Group); the client's yacht is not pictured.

31.8

Yacht Length (m)

Guest Capacity

Control Protocols

Light Points Verified

Mangusta 104 REV motor yacht under way, manufacturer photograph — Manufacturer photographs of the Mangusta 104 REV model. The client's yacht is not pictured. Photos: Mangusta Yachts, Overmarine Group.

The Challenge

The yacht's lighting runs on KNX with DALI drivers, installed by others and controlled by the crew from an iPad. Part of the DALI lighting had stopped responding to the control system, and replacement hardware fitted on board had not resolved it. The DALI driver layer was inconsistent: not every driver matched the rest of the installation, and replacement drivers had not been addressed or commissioned, so the control system could not manage them. The work had to be carried out on board, at the berth.

Our Solution

Haus Logic carried out diagnostics across the KNX and DALI layers, tracing the affected lighting back to its drivers and comparing it with the working installation. Driver hardware was matched to the rest of the system. A replacement DALI driver ships without a short address or group, so a control system cannot manage it until it is commissioned. Haus Logic addressed and grouped the drivers, re-programmed the affected lighting and commissioned it, then verified dimming and switching from the onboard control app.

Results & Impact

Reliable dimming and switching from the onboard control app

DALI drivers matched, addressed and commissioned

KNX and DALI lighting control verified on board

Completed on board at the berth

Client

Private Yacht Owner

Location

Abu Dhabi, UAE

Year

2026

Scope of Work

KNX and DALI diagnostics
DALI compatibility resolution
DALI addressing
Re-programming and commissioning
Control app verification
Testing & handover

Technologies

KNX lighting controlDALI integrationMarine automationDALI compatibility resolutionFault finding on existing systemsRe-programming and commissioningOn-board service at the berthAMC available for yachts

Annual maintenance contracts for yachts

Haus Logic provides annual maintenance contracts (AMC) that protect onboard lighting and control systems and minimise operational risk: planned visits on board, checks of the KNX and DALI lines, drivers and gateways, tested firmware updates, up-to-date system documentation, and priority response when something fails. Contracts cover yachts berthed in the UAE, including systems installed by others.
